DS200 INLET
37-28043-972
Specifications
- 200 A
- 480 VAC
- Type 4X
- 100 hp
| Rated Current (A) | 200 A |
|---|---|
| Rated Voltage (V) | 480 VAC |
| Horsepower Rating | 100 hp |
| Contact Configuration | 3P+G |
| Auxiliary Contacts | +2 AUX |
| Ratings Information |
SWITCH RATED BRANCH CIRCUIT DISCONNECT SWITCH MOTOR CIRCUIT DISCONNECT SWITCH |
| Environmental Rating |
Type 4X IP 66/67 |
| Short Circuit Rating | 10 kA - CLOSE & WITHSTAND |
| Impact Rating | IK10 |
| Material | METAL |
| Metal Type | ALUMINUM |
| Product Color | METAL |
| Minimum Operating Temperature |
-40F -40C |
| Maximum Operating Temperature |
140F 60C |
| Wiring Capacity - Phase Contacts |
4 AWG – 4/0 AWG SCREW TERMINAL |
| Applicable Standards |
UL 2682 UL 1682 cCSAus C22.2 No. 182.1-13 |
| Accessory Size | 6 |
| Base Drawing Number | 37-28xxx.PDF |
| Catalog | meltric-catalog-ds200-en.pdf |
| Instructions | meltric-instruction-ds-dsn.pdf |
