DSDC2 RECEPTACLE
37-24209-NC
Specifications
- 200 A
- 250 VDC
- Type 4X
| Rated Current (A) | 200 A |
|---|---|
| Rated Voltage (V) | 250 VDC |
| Contact Configuration | 2P+G |
| Ratings Information |
NON-CURRENT INTERRUPTING |
| Environmental Rating |
Type 4X IP 66/67 |
| Impact Rating | IK10 |
| Material | METAL |
| Metal Type | ALUMINUM |
| Product Color | BLUE |
| Minimum Operating Temperature |
-40F -40C |
| Maximum Operating Temperature |
140F 60C |
| Wiring Capacity - Phase Contacts |
4 AWG – 4/0 AWG SCREW TERMINAL |
| Applicable Standards |
UL 1682 cCSAus C22.2 No. 182.1-13 |
| Option(1) | SELF-RETURNING LID |
| Accessory Size | 6 |
| Base Drawing Number | 37-24xxx-xxx.pdf |
| Catalog | meltric-catalog-dsdc-en.pdf |
| Instructions | meltric-instruction-dsdc.pdf |
