DS100C HAZ RECEPTACLE
36-64233-C-K16-264-HAZ
Specifications
- 100 A
- 208 VAC
- Type 4X
- 20 hp
| Rated Current (A) | 100 A |
|---|---|
| Rated Voltage (V) | 208 VAC |
| Horsepower Rating | 20 hp |
| Contact Configuration | 3P+G |
| Auxiliary Contacts | +4 AUX |
| Ratings Information |
NON-CURRENT INTERRUPTING |
| Environmental Rating |
Type 4X |
| Short Circuit Rating | 100 kA - CLOSE & WITHSTAND |
| Impact Rating | IK09 |
| Material | METAL |
| Metal Type | ZAMAK |
| Product Color | BLACK |
| Minimum Operating Temperature |
-40F -40C |
| Maximum Operating Temperature |
140F 60C |
| Wiring Capacity - Phase Contacts |
10 AWG – 2 AWG SCREW TERMINAL |
| Applicable Standards |
cCSAus C22.2 No. 182.1-07 |
| Accessory Size | 4 |
| Base Drawing Number | 36-64xxx-C-Kxx-xxx-haz.pdf |
| Catalog | meltric-catalog-zone2-ds100c-en.pdf |
| Instructions | meltric-instruction-zone2.pdf |
