DS30 INLET
33-38217-K04-974
Specifications
- 30 A
- 277/480 VAC
- Type 3R
- 3 hp/15 hp
| Rated Current (A) | 30 A |
|---|---|
| Rated Voltage (V) | 277/480 VAC |
| Horsepower Rating | 3 hp/15 hp |
| Contact Configuration | 3P+N+G |
| Auxiliary Contacts | +4 AUX |
| Ratings Information |
SWITCH RATED BRANCH CIRCUIT DISCONNECT SWITCH MOTOR CIRCUIT DISCONNECT SWITCH |
| Environmental Rating |
Type 3R IP 54 |
| Short Circuit Rating | 100 kA - CLOSE & WITHSTAND |
| Impact Rating | IK09 |
| Material | POLY |
| Product Color | BLUE |
| Wiring Capacity - Phase Contacts |
14 AWG – 4 AWG SCREW TERMINAL |
| Applicable Standards |
UL 2682 UL 1682 cCSAus C22.2 No. 182.1-13 |
| Option(1) | SPARE POSITION |
| Accessory Size | 3 |
| Instructions | meltric-instruction-ds-dsn.pdf |
