DR7c RECEPTACLE
31-34961-173
Specifications
- 50 A
- 600 VAC/130 VDC
| Rated Current (A) | 50 A |
|---|---|
| Rated Voltage (V) | 600 VAC/130 VDC |
| Contact Configuration | 6P+G |
| Auxiliary Contacts | +3 AUX |
| Ratings Information |
NON-CURRENT INTERRUPTING |
| Environmental Rating |
Type 4X IP 66/67 IP 69 |
| Impact Rating | IK09 |
| Material | POLY |
| Product Color | BLUE |
| Minimum Operating Temperature |
-40F -40C |
| Maximum Operating Temperature |
140F 60C |
| Wiring Capacity - Phase Contacts |
14 AWG – 8 AWG SCREW TERMINAL |
| Applicable Standards |
UL 1682 |
| Accessory Size | 4 |
| Base Drawing Number | 31-349xx.PDF |
| Instructions | meltric-instruction-dr-dr7c.pdf |
