DR7c RECEPTACLE

31-34941

Specifications

  • 50A
  • 600 VAC/130 VDC
  • IP54/IP55
Rated Current (A) 50A
Rated Voltage (V) 600 VAC/130 VDC
Contact Configuration 4P+G
Auxiliary Contacts NO AUX
Ratings Information NON-CURRENT INTERRUPTING
Environmental Rating IP 54/55
Impact Rating IK08
Material POLY
Product Color BLUE
Minimum Operating Temperature -40F
-40C
Maximum Operating Temperature 140F
60C
Wiring Capacity - Phase Contacts 14 AWG – 8 AWG
SCREW TERMINAL
Accessory Size 3
Base Drawing Number 31-349xx.pdf
Catalog meltric-catalog-ds7c-dr7c-en.pdf
Instructions meltric-instruction-dr-dr7c-ds7c.pdf
