PNCX INLET
06E8007
Specifications
- 250 VAC
- IP66/IP67/IP69
| Rated Voltage (V) | 250 VAC |
|---|---|
| Contact Configuration | 4P+G |
| Ratings Information |
NON-CURRENT INTERRUPTING |
| Environmental Rating |
IP 66/67/69 |
| Impact Rating | IK08 |
| Material | POLY |
| Product Color | BLACK |
| Cable Range | .40-.55" |
| Minimum Operating Temperature |
-4F -20C |
| Maximum Operating Temperature |
158F 70C |
| Wiring Capacity - Phase Contacts |
18 AWG – 12 AWG SCREW TERMINAL |
| Accessory Size | P |
| Base Drawing Number | 06E8007.PDF |
| Catalog | meltric-catalog-pncx-en.pdf |
| Instructions | meltric-instruction-pncx.pdf |
