DSN12c RECEPTACLE
63-A4001-375-843
Specifications
- 15 A
- 480 VAC/ VDC
- Type 4X & IP69
| Rated Current (A) | 15 A |
|---|---|
| Rated Voltage (V) | 480 VAC/ VDC |
| Contact Configuration | 11P+G |
| Ratings Information |
NON-CURRENT INTERRUPTING |
| Environmental Rating |
Type 4X IP 69 |
| Impact Rating | IK09 |
| Material | POLY |
| Product Color | BLUE |
| Minimum Operating Temperature |
-40F -40C |
| Maximum Operating Temperature |
140F 60C |
| Wiring Capacity - Phase Contacts |
18 AWG – 14 AWG SOLDER/CRIMP TERMINAL |
| Applicable Standards |
UL 2238 |
| Option(1) | MUSHROOM PAWL |
| Option(2) | PADLOCK PAWL |
| Accessory Size | 1 |
| Base Drawing Number | 63-A4001.pdf |
| Catalog | meltric-catalog-dsn12c-en.pdf |
| Instructions | meltric-instruction-pn-ds-dsn-multipin.pdf |
