Images may not reflect actual product configuration
DS37c RECEPTACLE
37-C4003-SS
Specifications
- 2 A/7.5 A
- 480 VAC/130 VDC
- IP54/IP55
| Rated Current (A) | 2 A/7.5 A |
|---|---|
| Rated Voltage (V) | 480 VAC/130 VDC |
| Contact Configuration | 36P+G |
| Ratings Information |
CURRENT INTERRUPTING |
| Environmental Rating |
IP 54/55 |
| Impact Rating | IK09 |
| Material | METAL |
| Metal Type | STAINLESS STEEL |
| Product Color | METAL |
| Minimum Operating Temperature |
-40F -40C |
| Maximum Operating Temperature |
140F 60C |
| Wiring Capacity - Phase Contacts |
18 AWG – 14 AWG SOLDER/CRIMP TERMINAL |
| Accessory Size | 3 |
| Base Drawing Number | 37-c4003-ss.pdf |
| Catalog | meltric-catalog-dsn37c-ds37c-en.pdf |
| Instructions | meltric-instruction-pn-ds-dsn-multipin.pdf |
