Images may not reflect actual product configuration
PN INLET
01N8093
Specifications
- 15 A
- 500 VAC
- IP66/IP67
| Rated Current (A) | 15 A |
|---|---|
| Rated Voltage (V) | 500 VAC |
| Contact Configuration | 3P+G |
| Ratings Information |
CURRENT INTERRUPTING |
| Environmental Rating |
IP 66/67 |
| Impact Rating | IK09 |
| Material | POLY |
| Product Color | BLUE |
| Minimum Operating Temperature |
-40F -40C |
| Maximum Operating Temperature |
140F 60C |
| Wiring Capacity - Phase Contacts |
14 AWG – 8 AWG SCREW TERMINAL |
| Accessory Size | 1 |
| Base Drawing Number | 01-n8xxx.pdf |
| Instructions | meltric-instruction-pn.pdf |
